A8X ADAM (PIECE)
A8X ADAM - Active nearfield monitor
The A8X adds to the AX-Series as a unique model because its power and radiation characteristics allow it to be used as both a nearfield and midfield monitor. It represents a particularly attractive entry-level model for midfield monitoring which offers transparent re...
Delivery
S2Store Genk (BE)
Plus- en minpunten
Omschrijving
A8X ADAM (PIECE)
A8X ADAM - Active nearfield monitor
The A8X adds to the AX-Series as a unique model because its power and radiation characteristics allow it to be used as both a nearfield and midfield monitor. It represents a particularly attractive entry-level model for midfield monitoring which offers transparent reproduction of higher frequencies, clear mids and an excellent transient response.
The extra large, front-positioned bass reflex ports are perfectly matched with the bass/midrange driver that has a 1.5" voice coil. Thus the A8X can play very low registers with a powerful punch, and the greatest possible precision. The 150 Watt PWM amplifier for the midrange speakers in conjunction with the 50 Watt A/B tweeter amp enable the A8X to generate impressive maximum sound pressure levels of 120dB per pair at one meter.
|
Mid-Woofer |
|
| Number | 1 |
| Basket Ø | 8.5" (220 mm) |
| Voice coil Ø | 1.5" (38 mm) |
| Cone material | Carbon/Rohacell/Glass Fiber |
|
Tweeter |
|
| Number | 1 |
| Type | X-ART |
| Diaphragm area | 4 inch² (2420 mm²) |
| Equiv. Diaphragm Ø | 2" (56 mm) |
| Velocity transform ratio | 4:1 |
| Diaphragm weight | 0.17 g |
|
Built-in Amplifiers |
|
| Mid-Woofer | 1 |
| Type | PWM |
| Amp. power RMS / music | 150 W / 225 W |
| Tweeter | 1 |
| Type | A/B |
| Amp. power RMS / music | 50 W / 75 W |
|
Control panel |
|
| Input Sensitivity | -∞ to +14 dB |
| High Shelf EQ > 5 kHz | ±6 dB |
| Low Shelf EQ < 300 Hz | ±6 dB |
| Tweeter gain | ±4 dB |
|
Input connectors |
|
| Analog | XLR / RCA |
|
General data |
|
| Frequency response | 38 Hz - 50 kHz |
| THD 90dB/1m > 100 Hz | ≤0.5 % |
| Max SPL with sine wave acoustic 100Hz to 3kHz at 1m | ≥112 dB |
| Max SPL per pair at 1m | ≥120 dB |
| Crossover frequencies | 2300 Hz |
| Input impedance | 30 KOhm |
| Weight | 28.7 lb (13 kg) |
| Magnetically shielded | No |
| Height x Width x Depth | 15.5" (400 mm) x 10" (255 mm) x 12.5" (320 mm) |
| Warranty | 5 Years |
Korte specificaties
| Housing | |
|---|---|
| Color | zwart |
| Sound | |
|---|---|
| Crossover frequency | 2300 Hz |
| Frequency response | 38 Hz - 50 kHz |
| THD (total harmonic distortion) | ≤0.5 % |
| Power | |
|---|---|
| Max SPL sound pressure level | ≥112 dB |
| Peak power | 349 W |
| RMS power | 200 W |
| Amplifier configuration | BI-amp |
| Amplifier class | PWM, A/B |
| Audio I/O | |
|---|---|
| Inputs | XLR, RCA |
| Features | |
|---|---|
| Monitor type | 2-weg |
