The DCP-24 MKII is the little brother of the DCP-26 MKII which has exact the same features but has four outputs instead of six. If you have a stereo sub top combination and want to get the maximum power out of your audio system, without the risk of any damage, this is the unit that gets the job done. Fully digital with all the features you need to tune and protect your sound system. The additional latest software is availible at the download section of the product page.

FEATURES:

• 48 Khz, 64Bits Sample rate
• 5 parametric EQ's each in- and output
• USB interface and user-friendly software included
• 50 User Presets

SPECIFICATIONS:

DSP:

• Sample rate: 48 kHz, 64 bits NXP (Philips) DSP

5-Bands Input EQ:

• EQ Selections: Allpass, Bell, High Shelf, Low Shelf, Notch
• EQ Frequency Selection: 20 to 20,000 Hz in 1 Hz steps on all EQ's

Delay:

• Output delay: Channel independent from 0 to 8 mS

5-Bands Output EQ:

• EQ Selections: same as input
• Type: Low Shelf 6, Low Shelf 12, High Shelf 6 and High Shelf 12

Crossovers:

• Types: Linkwitz Riley, Bessel and Butterworth
• Slopes: 6, 12, 18, 24 dB/octave
• Crossover frequencies: 20 to 20,000 in 1 Hz octave steps

Limiter:

• Threshold points: -20 to +20 dBu in 0.5 dB steps
• Attack time: Zero Attack Time Limiter
• Release times: 1 = shortest, 100 = endless long, in steps of 1.

Miscellaneous:

• Memory Storage: 50 User presets
• Mute: All Output channels can be individually muted
• Display: 2 x 16 dot matrix characters
• Latency: 1.27 mS
• USB Interface: Back
• Power Supply: 6V DC
• Power Consumption: 4 Watt
• Power Switch: Back
• Measurements: 483 x 155 x 44 mm

DOWNLOADS:

Manuals

•  D2083_MANUAL_GB_V1

Product files & software

•  D2083_ DCP-24_Sub_Top_General_Settings
•  D2083_DSP_CONTROL_Software
•  D2083_DSP_CONTROL_WIN81_INSTALL_GUIDELINE
