ELX200-18SP Electro-Voice Active Subwoofer
ELX200-18SP 18-inch Active Subwoofer ELECTRO-VOICE
ELX200-18SP features highly efficient Class-D power amplifiers (up to 1200 W) with integrated QuickSmartDSP, and delivers SPL up to 132 dB using EV-designed and manufactured transducers (18-inch EVS-18L woofer). Active subwoofer models can be easily set via three presets (Music, Live, Club), sub/top system-match crossovers...
Delivery
S2Store Genk (BE)
Combination deal
ZLX-15P G2 Full Stack
2x
4x- 2x ZLX-15P-G2 Electro-Voice Active Speaker€1.212,00
- 4x ELX200-18SP Electro-Voice Active Subwoofer€4.340,00
- 4x €0,00
Combination deal
ZLX-15P G2 Half Stack
2x
2x
2x
2x- 2x ZLX-15P-G2 Electro-Voice Active Speaker€1.212,00
- 2x ELX200-18SP Electro-Voice Active Subwoofer€2.170,00
- 2x 21337 DISTANCE ROD BLACK K&M€102,00
- 2x CPM3FM Cordial XLR Audio Signal cable (3m)€44,00
Combination deal
2x ZLX-12P + ELX200-18SP SUB
2x
2x
2x
2x- 2x ZLX-12P-G2 Electro-Voice Active Speaker€1.026,00
- 2x ELX200-18SP Electro-Voice Active Subwoofer€2.170,00
- 2x 21337 DISTANCE ROD BLACK K&M€102,00
- 2x CPM3FM Cordial XLR Audio Signal cable (3m)€44,00
Combination deal
ELX200-12P Set + subwoofers
2x
2x
2x- 2x ELX200-12P ELECTRO-VOICE Active Speaker€1.478,00
- 2x ELX200-18SP Electro-Voice Active Subwoofer€2.170,00
- 2x 21337 DISTANCE ROD BLACK K&M€102,00
- 2x €0,00
Combination deal
ELX200-18SP COVER BUNDLE


- 1x ELX200-18SP Electro-Voice Active Subwoofer€1.085,00
- 1x ELX200-18S-CVR Electro-Voice Cover for ELX200-18S and ELX200-18SP€109,00
Plus- en minpunten
Omschrijving
ELX200-18SP Electro-Voice Active Subwoofer
ELX200-18SP 18-inch Active Subwoofer ELECTRO-VOICE
ELX200-18SP features highly efficient Class-D power amplifiers (up to 1200 W) with integrated QuickSmartDSP, and delivers SPL up to 132 dB using EV-designed and manufactured transducers (18-inch EVS-18L woofer). Active subwoofer models can be easily set via three presets (Music, Live, Club), sub/top system-match crossovers, three-band EQ, five user-programmable presets (save and recall
settings), visual monitoring of limiter status, input level control and meters, and master volume control for optimal gain structure. The ELX200 self-powered models are ideal for portable and installed applications, with their lightweight and compact 15-mm wood enclosures, integrated M20 thread for pole mounting plate, and design with two handles for easy lifting.
With the new QuickSmart Mobile wireless control and monitoring application, which uses Bluetooth Low Energy Technology (BTLE), up to six self-powered ELX200 speakers can be controlled, configured and monitored simultaneously. Receive alerts when your system is overloaded and operate your system while standing in front of your speakers, not behind them. Bluetooth is available in certain countries.
Korte specificaties
| Housing | |
|---|---|
| Dimensions | 600 mm x 507 mm x 574 mm |
| Weight | 29.0 kg |
| Color | Zwart |
| Construction material | 15 mm plywood with EVCoat |
| Stand | |
|---|---|
| Stand adapter (top hat) | M20 |
| Sound | |
|---|---|
| Crossover frequency | Adjustable 80 Hz, 100 Hz, 120 Hz, 150 Hz |
| Frequency response | 47 Hz - 105 Hz¹ (-3 dB) |
| Frequency range | 40 Hz - 145 Hz¹ (-10 dB) |
| LF driver | EVS-18L 457 mm (18 inch) |
| SPL | 132 dB |
| Power | |
|---|---|
| Peak power | 1200 W |
| Amplifier class | D |
| Power supply | |
|---|---|
| Consumption | 100 - 240 V~, 50 - 60 Hz, 1.2 ~ 0.6A |
| Audio I/O | |
|---|---|
| Inputs | (2) XLR/TRS combo jacks |
| Outputs | (2) XLR link outputs |
