LIVERACK-10 PA-Mixer JB Systems

The JB Systems LIVERACK-10 is a versatile PA mixer with 10 inputs over 7 channels in a convenient 19" rack format. In addition to four mic/line and two mic/stereo line inputs, the PA mixer has a USB port. An internal media player supports WMA, WAV, FLAC, APE and MP3 audio formats. In addition, the LIVERACK-10 features a Bluetooth receiver.

The microphone inputs have switchable +48V phantom power so you can connect sensitive condenser microphones for instruments or vocals. In addition, each mono channel has a -20 dB PAD switch that lets you mute loud instruments. You can also use the media player as a mono MP3 recorder, and record the mix directly to a connected USB stick. You can also connect the LIVERACK-10 to your computer via USB to play media or record a mix.

• Multi-purpose PA mixer in a handy 19” Rack format.
• 10 inputs on 7 channels (4 mic/line, 2 mic/stereo line, 1 player/stereo in/usb).
• The USB connector is Bidirectional (for mono recording or stereo playback via PC/Mac).
• Internal WMA, WAV, FLAC, APE and MP3 media player for USB memory sticks.
• The media player can also be used as a mono mp3 recorder (128kbps).
• Integrated Bluetooth receiver.
• Internal 32bit DSP-effect unit with 16 effects + separate parameter control
• Input control on all the channels:
  • Gain (not on input 9-10/media player)
  • Pan
  • Low Cut switch (not on input 9-10/media player)
  • Treble, mid, bass (Treble, bass on input 9-10/media player)
  • Aux send (Post Fader)
  • Effect send
  • Channel level
  • PFL button (not on input 9-10/media player)
• General 48V Phantom Power switch.
• 1 Master + 1 Group output with individual level control.
• Aux Send output + Return input with individual level control.
• Headphones + control room outputs with level control.
