PHANTOM 225 LED SPOT SHOWTEC

The Phantom 225LED Spot is an extremely powerful LED movinghead with a 225W LED source. This unit gives even more light-output than the popular Phantom 575 (MSR 575 bulb). The Phantom 225LED spot is equipped with 7 Gobos and 7 Dichroic filters. It has a lot of functionalities to make a creative lightshow: gobo-shake, gobo-rotate, prism, split & rainbow colors. It has a stylish design with a rubber paint finish. The gobos can be changed very easily by a handy lid. It has a basic (9) and advanced (14) DMX personality. The menu with 36 character display makes it easy to control the settings. If you like to operate without controller you can use the 16 built in programs which can run automatically, sound-active or by master/slave mode. Check the online product video for more details.

Features

• 73,100 Lux @ 1 M

• 7 Rotating Gobos & 8 Colors

• 16 Built-in programs selectable by DMX

• Menu with 36 character display

• Motorized focus

Specifications

Output

• Lux @ 1m: 73,100

• Beam Angle: 19°

• Light Source: 3 x 75W White LED

Electrical

• Input Voltage: 100-240 VAC

• Power consumption: 375W max. at full output

• LED Drive Current: 16.5

Control

• On-Board: 16x2 Character display, auto,

• Sound control & Master/Slave mode

• Control Protocol: DMX512

• Control Personality: Advanced 14ch /Basic 8ch

Optical system

• Dimmer: 0-100%

• Strobe: 0-20Hz

• Focus: Motorized

• Prism: 3-facet prism

Movement

• Pan: 540°

• Tilt: 270°

• Pan/Tilt resolution: 16 bit

• Special: Pan / Tilt movement blackout,

• User-selectable Pan & Tilt ranges, 540°/360°/180°

• Reverse Pan / Tilt movement

Gobos & Colors

• Gobo: 1 glass + 6 metal gobos (replaceable)

• Gobo functions: Gobo-flow effect,Gobo shake

• Rotation: Bi-directional

• Gobo inner diameter: 23mm

• Gobo outer diameter: 27mm

• Colors: 7 dichroic-filters + white

• Color functions: Split colors, Rainbow-flow effect

Physical

• Color: Black

• Housing: Metal & Flame-retardant plastic

• Fixture Connection: XLR Data in/out, IEC Power in

• Dimensions (WxDxH): 423 x 303 x 552 mm

• Weight: 20,5 kg

Certification and Safety

• Certification: CE

• Max. ambient Temp.: 40°C
